Yamaha Pro Audio DXR12 mk3 12" 2-Way Powered Loudspeaker

Yamaha DXR12 mk3 powered loudspeaker

The DXR12 mk3 is a 12-inch, two-way powered speaker for live performance, DJ sets, presentations, and events. Its onboard display and D-Remote app put system adjustments within reach, whether the speaker is beside you or mounted out of reach.

Key features

• Onboard color LCD: Access crossover, EQ, delay, D-Mode, feedback suppression, and ducker controls. Store up to eight user presets.
• D-Remote app: Control up to 10 speakers, group systems, switch Auto EQ and Auto HPF presets, and adjust processing and Bluetooth playback from an iOS or Android device.
• Bluetooth audio streaming: Play music or accompaniment wirelessly from a mobile device.
• Class-D amplifier: 2,000 W peak (1,000 W RMS) power rating, with newly developed transducers and refined porting.

Specifications

• Speaker design: Two-way, bi-amplified, bass-reflex powered speaker
• Frequency range (-10 dB): 50 Hz–20 kHz
• Coverage: 90° horizontal × 60° vertical
• Crossover: 1.8 kHz, FIR-X tuning (linear-phase FIR filter)
• Maximum output: 134 dB SPL (measured peak, IEC noise at 1 m)
• Drivers: 12-inch low-frequency cone with 2.5-inch voice coil; 1.75-inch high-frequency diaphragm with 1-inch throat compression driver
• Amplifier: Class D; peak 2,000 W (LF 1,700 W, HF 300 W); RMS 1,000 W (LF 850 W, HF 150 W)
• Cooling: Five-speed fan
• Power consumption: 120 W (1/8 power), 35 W (idle)
• Power requirements: 100–240 V, 50/60 Hz
• Conversion: 32-bit/96 kHz sampling
• Processing: HPF off or 50–118 Hz, 12–48 dB/octave; DSP modes: FOH/Main, Monitor, DJ, Live Music, Speech, Off
• Analog inputs: Input 1: combo × 1, 20 kΩ balanced / 10 kΩ unbalanced, maximum +24 dBu; Input 2: combo × 1, 6 kΩ balanced / 3 kΩ unbalanced, maximum +24 dBu line or -6 dBu mic
• Analog outputs: Output 1: XLR3-32 thru; Output 2: XLR3-32 thru or DSP out
• Bluetooth: Version 5.0, A2DP (SBC, AAC), Class 1
• App: D-Remote for iOS and Android
• Cabinet and finish: Plastic, black
• Handles: Two side handles
• Pole sockets: Two 35 mm sockets on bottom (0° or -7°)
• Rigging: Two top and one rear positions for M10 × 18 mm eyebolts; two bottom and two side positions for M8 × 25 mm UB-DXRDHR12A
• Floor monitor angle: 52°
• Dimensions (product, not packed): 14.4 in W × 13.8 in H × 13.8 in D (366 × 350 × 350 mm)
• Net weight (not shipping weight): 38.4 lb (17.4 kg)
• Optional accessories: UB-DXRDHR12A U-bracket; SPCVR-DXR123 cover
