An 8x8 Interface for Your StageConnect Network
The Midas DN4888 provides a dead-simple solution for piping eight channels of analog I/O over a StageConnect network. This bus-powered interface features eight line-level analog inputs, eight line-level analog outputs, and two Ethernet ports: one to connect to Ultranet receivers, and a second to output the eight onboard analog input channels. Configuring the DN4888 is a piece of cake via a built-in Synchronization switch. You also get an LED that indicates a successful connection to a StageConnect network, plus a power LED and a USB port for firmware updates.
Midas DN4888 StageConnect Interface Features:
- A great solution for piping 8 channels of analog I/O over a StageConnect network
- 8 XLR/TRS combination inputs and 8 XLR outputs accommodate line-level analog signals
- 2 Ethernet ports: 1 to connect to Ultranet receivers; 1 to output the 8 onboard analog input channels
- Built-in Synchronization switch configures the unit for either 8x8 or 16x8 Slave operation
- Status LED indicates a successful connection to a StageConnect network
- Power LED signals whenever power is received from an external adapter or via a StageConnect bus
- USB port makes firmware updates a breeze
Tech Specs
- Type:Stage Box
- Compatibility:Midas ULTRANET, StageConnect
- Channels:32 x 32
- Inputs - Line:8 x XLR-1/4" combo
- Outputs - Main:8 x XLR
- Data I/O:2 x StageConnect XLRs, 2 x RJ45
- USB:1 x Type B
- Rackmountable:Yes, 1U
- Power Source:12V DC Power Supply
- Height:1.9"
- Depth:6.7"
- Width:19"
- Weight:4.9 lbs.
- Manufacturer Part Number:000-DW102-00010
