Earthquaker Spatial Delivery V3 Envelope Filter w/ Sample & Hold guitar pedal

Spatial Delivery®Envelope Filter with Sample & Hold<<< English >>>We proudly present the new and improved Spatial DeliveryEnvelope Filter!We took thealreadycosmic, originalSpatial Deliveryand added six available preset slots for you tostore your preferred settings–whether they be dissonant sweeps, rhythmic auto-wahfrequencies,oscillating robot gibberishor honestly whateverfiltered frequency funyouwant. Even theexpression jack assignment can be saved and recalled in any of theslotsso that the signature sounds you dial in are readily available with a quick tap of the

2. switch.Save your settings confidently on the go thanks to the two modes indicated bythe LEDSave/Recallswitch.And of course, for all of you Spatial Deliverydiehards, all the familiar features of theoriginal are still in place. This baby has three modes with the switchableUp Sweep,Down Sweep, andSample&Holdfunctions, along withRange,ResonanceandFiltercontrols. Get some wild filter sweeps with theUpandDownmodes andadjust theRangetocontrol the sensitivity and reaction time of the envelope,which altersthe widthof the frequency sweep.In theSample&Holdmode, the filter is controlled by randomvoltage and theRangecontrols the speed.The filter can be crossfaded between highpass, band pass and low pass for a wide variety of voices. TheResonancecontrol goesfrom zero to the brink of oscillation and adds more body and ring to the filter voice.CONTROLSMode:This toggles between upward sweep, downward sweep or sample and hold.Range:Adjusts the sensitivity of the envelope in Up and Down mode. In Sample andHold mode, this controls the speed.Filter:This crossfades between high pass and low pass filtersand allows you to geteverything in between. High pass is fully counterclockwise, low pass is full clockwiseand center is band pass. This is much more useful than a simple switch you wouldtypically find on a multi-mode because it allows you to blend thefilters for differentsounds!Resonance:This is the filter feedback control. It adds more body and ring to the filtervoice.Presets:Six available preset slots for you to save and recall your favorite settings! Thesettings for each of the three controls, the mode switch and the expression jackassignment can be saved and recalled in any of the slots.GLOBAL FEATURESPresetsSpatial Delivery boasts six presets and on-the-fly footswitch preset switching, withexpression control that can be mapped to different controls and can also be saved as apreset. Saving, recalling and overwriting presets has never been simpler.
4.

   OperatingModesSpatial Delivery has two operating modes which are indicated by the color of theSave/Recallswitch LED. In Live Mode, the pedal will operate exactly where the controlsare set,and any changes will have no effect on the presets unless saved. In PresetMode, stored presets are selected using thePresetswitch, and the physical settings ofthe controls will be ignored.User-Assignable Expression ControlUse any TRS expression pedal toeasilytake control over theRange,ResonanceorFiltercontrols,allowing for limitless experimentation.FLEXI-SWITCH® TECHNOLOGYThis device features Flexi-Switch Technology! This relay-based, true bypass switchingstyle allows you to simultaneously use momentary and latching style switching.For standardlatching operation:Tap the footswitch once to activate the effect andthen tap again to bypass.For momentary operation:With the effect off, hold the footswitch down for as long asyou’d like to use the effect. Once you release the switch, the effect will be bypassed.Since the switching is relay-based, it requires power to pass signal.POWER REQUIREMENTSCurrent Draw:75 mAThis device takes a standard9-voltDC power supply with a 2.1mm negative centerbarrel. We recommend using a pedal-specific, transformer-isolated, wall-wart powersupply or a power supply with multiple isolated-outputs. Pedals will make extra noise ifthere is ripple or unclean power.Switching typepower supplies, daisy chains and non-pedal specific power supplies do not always filter dirty power and may result inunwanted noise.DO NOT RUN AT HIGHER VOLTAGES! YOU HAVE BEEN WARNED.TECH SPECSInput Impedance: 500 kΩOutput Impedance: 100 ΩWARRANTY
